Liquid Washing Cosmetic Mixing Machine Homogenizing Mixer Welded Pot Body
QHM-LIQUID WASHING HOMOGENIZING MIXER
PERFORMANCES AND FEATURES:
◆ The all-round wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of different processes according to customer requirements.
◆ The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many indissoluble materials such as AES, AESA, LSA, etc. during the liquid detergent production process so as to save energy consumption and shorten production period.
◆ The pot body is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements.
◆ According to customer requirement, the tank can heat and cool materials. The heating way including steam heating and electric heating. Easy to discharge, bottom direct discharge or by transfer pump.
| Heating type |
Electric heating, water recycling, thermal oil, steam, far infrared heating. |
| Charging type |
Charging from above, discharging from bottom or above. |
| Shaft |
Adopt self-lubricating wear-resistant sleeve, suitable for mixing various media. |
| Stirring type |
Paddle type or anchor type or as per customer request |
| Seal type |
Magnetic seal, mechanical seal, packing seal, gasket seal. |
The machine can produce shampoo,shower gel,lotion, hand sanitizer,any kind of liquid mixing.
Liquid washing mixer: Three layers. The outer is made of SUS304-2B stainless steel, thickness3 mm; middle layer is made of SUS304-2B stainless steel, thickness 4 mm; Iner layer is made of SUS316L stainless steel, thickness 4mm. (3jackets one is for heating when mixing product, another is for cooling when finished mixing) mixing power is 2.2 KW, mixing speed is 0-65r/min, A high speed homogenizer at the bottom which power is 4 kw, the speed can reach 3000r/ min.
|
型号
model
|
50型Type 50 |
100型
Type 100
|
150型
Type 150
|
200型
Type
200
|
300型Type 300 |
400型Type 400 |
|
|
|
浆叶形式
Paddle form
|
S式单浆
S type single pulp
|
|
工作容积(L)
Working volume (L)
|
50 |
100 |
150 |
200 |
300 |
400 |
|
|
|
搅拌浆转速(r/min)
Rotating speed of stirring paddle (r/min)
|
24 |
|
倒拌角度
Upside-down angle
|
<105° |
|
搅拌电动(kw)
Stirring electric (kw)
|
1.5 |
2.2 |
3 |
4 |
5.5 |
5.5 |
|
|
|
倒料电机(kw)
Pour motor (kw)
|
0.37 |
0.55 |
0.55 |
0.75 |
1.1 |
1.1 |
|
|
|
外形尺寸 (mm)
Dimensions (mm)
|
1200×500×950 |
1400×580×1000 |
1800×600×1150 |
2000×650×1200 |
2150×700×1250 |
2280×750×1250 |
|
|
|
重量(kg)
Weight (kg)
|
280 |
350 |
410 |
450 |
520 |
580 |
|
|
Qihang according to wishes designed to meet both the technical requirements and investment plan to match the best solution. And relying on their own understanding of the technology industry and the cosmetics industry professional self-control team, committed to the professional digital solutions to provide the best quality customer service.
PROJECT CASES:
Manage ltem: vacuum homogenizing emulsifiers, high shear liquid detergent mixers, reverse osmosis ion water devices, various water injection, liquid and ointment semi-automatic and automatic filling production lines, round and flat bottles automatic and semi-automatic labeling machines, perfume whole-set production lines, laboratory equipment, flow lines, etc.
